2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension

2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension

  • 2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension
  • 2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension
  • 2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension
  • 2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension
2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension
Détails sur le produit:
Lieu d'origine: Canton, Chine
Nom de marque: GUOMAT
Certification: ISO/Ts16949:2009
Numéro de modèle: 2B6910
Conditions de paiement et expédition:
Quantité de commande min: 6pcs
Prix: $59.9-69.9/pc
Détails d'emballage: Emballage en carton ou selon les exigences du client
Délai de livraison: 5-8 jours ouvrables
Conditions de paiement: LC, T/T, Western Union
Capacité d'approvisionnement: 10 000 par semaine
Contact
Description de produit détaillée
Nom de type: Sacs à ressorts pneumatiques en suspension Matériau du ressort: Caoutchouc naturel
Qualité: 100% testé Garantie: 12 mois
couleur: Noir Bonne année: 2B9-200
Position: Arrière Usage: Une voiture, un camion, une remorque, etc.
Mettre en évidence:

Goodyear RV air suspension spring

,

Contitech replacement air spring

,

FD 200-19 air spring

2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension
Product Overview

The 2B9-200 Goodyear Replacement Air Spring is a high-quality suspension component designed for RV applications, providing enhanced load-bearing capacity and improved driving comfort.

Cross Reference Numbers
Goodyear OEM Numbers
2B9-200 2B 9-200 2B9 200 578-92-3-202 578 92 3 202 578923202
Contitech OEM Numbers
64267 FD200-19 320 FD 200-19 320
Firestone OEM Numbers
6910 W01-358-6910 W01 358 6910 W013586910
Other Manufacturer References
AUTOMANN ABSP2B12R-6910 DAYTON 354-6910 DINA A-8127-19 GRANNING 1371 HDA PMABG-6910B HENDRICKSON 45843-3 / B-8768 INT'L/NAVISTAR 554783C1 LOAD GUARD SC2011 MASA 227138412 PREVOST 63-0173 R&S TRUCK & BODY 1027405 RIDEWELL 1003586910C / S-4512-C SPRINGRIDE 2B9-492 TAURUS AS218-6910 TRIANGLE 4320 TRP A69100 WATSON & CHALIN AS-0001
Installation & Dimensional Data
Parameter Top Plate Bottom Plate
Mounting Holes/Studs 3 2
Plate Diameter 6.4 in 6.4 in
Bolt Circle Diameter (C to C) 3.5 in 3.5 in
Alignment - Parallel
Additional Specifications
  • Internal Bumper: Not Included
  • Min. Height: 3.2 in
  • Max. Height: 10.8 in
  • Total Stroke: 7.6 in
RV Air Spring Application Guide

Air springs in RVs are primarily used to improve suspension comfort, enhance load-bearing capacity, and improve overall vehicle stability during long journeys.

GUOMAT air springs are widely applicable to Class B and Class C RVs and various recreational vehicle chassis.

1. Rear Axle Assist Load Bearing

The rear of an RV is heavily loaded, and the original leaf springs tend to sag. Air springs provide additional support, resulting in:

  • Reduced rear-end sag
  • Reduced sway, improving driving stability
  • Protecting chassis and suspension components
2. Improved Driving Comfort

Air springs absorb minor vibrations, making the vehicle smoother on highways, bumpy roads, or campground roads.

Benefits include:

  • Significantly reduced bumps
  • Reduce vibration of interior furniture and equipment
  • Improved long-distance travel experience
2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension 0 2B9-200 Goodyear Replacement Air Spring FD 200-19 320 Contitech RV Air Suspension 1
